CR10-100-2.5-S/F Hydraulic Damper
Linear damping without free travel
Max. force: 130±2N, Max. stroke: 79mm.
Damping technology applied to soft close bedroom door dampers to reduce the speed of the movement is becoming an everyday necessity. The Coricher CR10-100-2.5-S/F soft close bedroom door damper is perfect for slowing down the sliding motion of doors. It prevents noisy and damaging collisions between the door components when closing or opening.
Depending your requirements, you can choose from a variety of different damping types from the following: push-in damping, pull-out damping, spring return damping and bi-directional damping.
Coricher high adaptability soft close bedroom door dampers are used in motion doors, sliding drawers, etc.
TECHNICAL DATA
Max stroke:
79mm
Tube length:
100mm
Max. force:
130±2N
Outer body diameter:
Ø10mm
Piston rod diameter:
Ø2.5mm
★Stable force performance:
Lifetime:
80,000 cycles
★Operating temperature:
-20 °C to +40 °C
Tube material:
Steel
Piston rod material:
Steel
Free-run:
No
PRODUCT DETAIL
Applications
Sliding drawers
Sliding doors
Lids
Sliding doors
Lids
