CR10-30-2.5-S/F Hydraulic Damper
Highest standards motion control without free travel
Damping force 2.5N to 80N, Max stroke 10mm.
Coricher CR10-30-2.5-S/F linear dampers are hydraulic components for retarding moving parts. They help to avoid closing impact and create a quiet and secure living or working environment for you. What’s more, they are maintenance-free, self-contained and sealed units.
We also provide customized solution to perfectly meet individual requirements.
Coricher hydraulic dampers as high-quality hydraulic components used in sliding drawers, motion doors, lids and multiple other applications.
TECHNICAL DATA
Max stroke:
10mm
Tube length:
30mm
Max compression force:
80N
Outer body diameter:
Ø10mm
Piston rod diameter:
Ø2.5mm
★Stable force performance:
√
Lifetime:
80,000 cycles
★Operating temperature:
-20 °C to +40 °C
Tube material:
Steel
Piston rod material:
Steel
Free-run:
No
PRODUCT DETAIL
Applications
Sliding drawers
Sliding doors
Lids
Sliding doors
Lids
Example
